Name: CE Verified PN-NP-C High Purity Nitrogen Generator 95%-99.9995%
Brand: JoShining Energy & Technology Co.,Ltd
SKU: PN-NP-C
Price: negotiable USD
Availability: InStock

Dom Produkty PSA Nitrogen Generator

CE Verified PN-NP-C High Purity Nitrogen Generator 95%-99.9995%

Szczegóły Produktu:

Place of Origin:	Suzhou
Nazwa handlowa:	SINCE-GAS
Orzecznictwo:	CE,ABS,DNV,CCS,LR,BV,ASME,GOST
Model Number:	PN-NP-C

Zapłata:

Minimum Order Quantity:	1 set
Cena:	negotiable
Packaging Details:	Normal standard exporting packing
Delivery Time:	2-3 months
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	70 sets per year

Kontakt

Szczegółowy opis produktu

Materiał:	Stal węglowa lub stal nierdzewna	Certyfikaty:	CE,ABS,CCS,BV,DNV,LR,
Nacisk:	8-10 barów	Czystość:	95%-99,9995%
Punkt rosy:	-40 - 70℃	Adsorbent:	CMS
Cechy:	Wysoka czystość
Podkreślić:	sa zakład azotowy , generator gazu azotowego psa , generator azotu z weryfikacją CE

CE verified PN-NP-C High purity nitrogen generator

Description :

1. Purity : 95%-99.9995%
2. Energy-saving
3. 20 years Working life
4. Automatic operating

NO	Item	Notes
1	Nitrogen	High purity 99.9995%
2	Energy	Excellent energy-saving
3	Working life	＞20 years
4	Operating method	Fully automatic
5	Certificates	CE,TUV,,CCS approved

PSA technology allows nitrogen molecules to be isolated from other molecules in compressed air (water, oxygen, CO2, etc). The carbon molecular sieve (CMS), the adsorbent in the generator, retains all those molecules and only lets the nitrogen pass through to the outlet. While one tower is filled with CMS, another tower for working, around 58 seconds for swtiching, the one tower filled with CMS will use nitrogen for regeneration, mainly release the CO2, oxygen etc , SINCE gas nitrogen purity can produce from 95%-99.9995% .

Technical features :
Principle: passage of compressed air through a bed of carbon molecular sieve (CMS) using presure swing adsorption technology, the most reliable on the market
N2 flow: 5-5000 Nm3/h
O2 purity: 1% to 10 ppm
On-line monitoring instrument
Digital hours counter Audible and visual maintenance indicator
Economy mode option: via pressure to enables the compressor shut & start-up when nitrogen supply is not required

Specifications :

No	Model	Capacity(Nm3/h)	Purity	Power(KW)	Overall size(mm)
1 2 3 4	PN-3-39 PN-5-29 PN-5-295 PN-8-295	3 5 5 8	99.9% 99.5% 99% 95%	0.5	180014001500
5 6 7 8	PN-5-49 PN-8-39 PN-12-295 PN-15-29	5 8 12 15	99.99% 99.9% 99.5% 99%	0.5	180014001800
9 10 11 12	PN-10-49 PN-15-39 PN-25-295 PN-30-39	10 15 25 30	99.99% 99.9% 99.5% 99%	0.5	200017002250
13 14 15 16	PN-15-49 PN-22-39 PN-35-295 PN-45-29	15 22 35 45	99.99% 99.9% 99.5% 99%	0.5	210018002200
17 18 19 20	PN-20-49 PN-30-39 PN-50-295 PN-60-29	20 30 50 60	99.99% 99.9% 99.5% 99%	0.5	220018002200
21 22 23 24	PN-30-49 PN-45-39 PN-75-295 PN-88-29	30 45 75 88	99.99% 99.9% 99.5% 99%	0.5	240019002200
25 26 27 28	PN-40-49 PN-60-39 PN-100-295 PN-120-29	40 60 100 120	99.99% 99.9% 99.5% 99%	0.5	250021002500
29 30 31 32	PN-50-49 PN-70-39 PN-120-295 PN-140-29	50 70 120 140	99.99% 99.9% 99.5% 99%	0.5	260022002850
33 34 35 36	PN-60-49 PN-90-39 PN-160-295 PN-190-29	60 90 160 190	99.99% 99.9% 99.5% 99%	0.5	280022002500
37	PN-80-49	80	99.99%	0.5
38 39 40	PN-120-39 PN-200-295 PN-250-29	120 200 250	99.9% 99.5% 99%	0.5	320014002800
41 42 43 44	PN-100-49 PN-140-39 PN-250-295 PN-290-29	100 140 250 290	99.99% 99.9% 99.5% 99%	0.5	350015002800
...	...	...	...	...	...
Note:More news please free to contact Since Gas System Co.,Ltd or send email to us directly

Application :

Nitrogen widely used following field :
Metal processing and laser cutting
Pharmaceuticals
Electronics
Food and beverage processing and storage
