Fully Automatic High Purity 99.9995% Hydrogen Dryer Equipment for Chemical

Fully Automatic High Purity 99.9995% Hydrogen Dryer Equipment for Chemical

Hydrogen dryers

Hydrogen dryer for hydrogen-cooled generators is a dual-absorber unit that continuously removes moisture from recirculated hydrogen, keeping the internal components of the turbine in a completely

dry hydrogen atmosphere. The unit uses regenerative type desiccant and is fully automatic

in operation. It is heat reactivated with embedded electric heaters.

Accomplishes reactivation with a completely closed-circuit system, thereby eliminating any purge loss

or infiltration of atmosphere into the system.

High quality desiccants

High quality, extra activated alumina is respectively filled in each tower ;

Controller Reliable Timed controller Field proven over time, this design and technology maintain precise

control over all switching and purge valve functions.

Opional for  PLC controller,PLC Controlling system

executes and monitors all dryer functions;

7 Colorful Touch screen panel displays dryer status.

Pressure Gauges Stainless steel gauges, located on each tower, provide visual indication of

pressure during drying and regeneration processes.

Product clean&pure compressed air

Pressure:≤5bar

Normal pressure dew point:≤－70℃

Capacity :50-5000Nm3/H
